6.5 Changing parameters in the standard menu (Pro)
The following parameters can be set in the standard menu:
Pulse mode Pu
Emptying time t
Number of cycles C
A description of the individual parameters can be found in section “6.1 Adjustable parameters”.
NOTE
The emptying time t can only be set on the lubricator when it is not controlled by an
external controller (Pu0 / time controlled).
Changing parameters
aLubricator in operation (PAU / On)
1. Hold the magnetic pin against the action field.
The LED flashes red and run, On, OFF, On and Pro are displayed in succession on the LCD.
2. Remove the magnetic pin when the display indicates Pro.
The display shows the parameters Pu, t and C in succession (depending on the lubricator type).
3. When the parameter to be set is displayed, hold the magnetic pin against the action field.
On the LCD the value for the parameter is incremented and starts again from the beginning
after reaching the highest value.
4. Remove the magnetic pin from the action field when the desired value is displayed.
The set value flashes twice.
The next parameter is displayed on the LCD.
After the last parameter the lubricator returns to operation again automatically.
