Operating manual Lubricator
Revision: 02
2022-D064493
en-21
3x
7x
Changing parameters
aLubricator ready for operation, but is not switched on (OFF)
1. Hold the magnetic pin against the action field.
The LED flashes red three times, then On is displayed on the LCD followed by OFF.
The LED flashes red seven times and EP is displayed on the LCD.
2. Remove the magnetic pin when the display indicates EP.
The LCD displays the first editable parameter.
3. Hold the magnetic pin against the action field to change the parameter.
On the LCD the value for the parameter is incremented and starts again from the beginning
after reaching the highest value.
4. Remove the magnetic pin from the action field when the desired value is displayed.
The set value flashes twice.
The next parameter is displayed on the LCD.
The current value flashes twice if the parameter is not changed.
After the last parameter the lubricator returns to standby mode again automatically (OFF).
