Wood-mizer LT70 Series User Manual

Maintenance
Alternator Belt
2
2-4 G28doc072321 Maintenance
2.7 Alternator Belt
Adjust the alternator belt as needed. Check the alternator belt for tension and wear when
battery is not charging properly or when the alternator belt is squeaking.
To Tighten The Belt:
3. Unscrew four bolts (A) and remove alternator belt cover.
See Figure 2-1.
FIG. 2-1
AR
A

Wood-mizer LT70 Series Specifications

General

Hydraulic Log Handling	Optional
Computer Setworks	Optional
Blade Width	1.5 inches (3.8 cm)
Power Options	Electric or diesel
Head Controls	Manual
Cutting Method	Horizontal bandsaw
