Wood-mizer LT70 Series User Manual

Operation
Engine Specifications
1
1-11 G28doc072321 Operation
Diagnostic Indicator light is on, engine RPM is limited to 2500 to avoid engine damage.
1.3 Engine Specifications
G57 Kubota
Type
Liquid cooled, 4-cycle, gasoline,
OHV, electronic fuel injection
Number of cylinders
4
Bore and stroke mm
79 x 78,4
Total displacement cm
3
1537
Power H.P. ( SAEJ 1995 ) [HP/min
-1
( rpm )]
57/3600
Max Torque [Nm /min
-1
( rpm )]
120/2400
Dry Weight kg [ lbs. ]
119 [262]
Fuel
Unleaded gasoline
CO2 Emission data g/kWh
1090
Oil Capacity (w/filter) l.
6L

Wood-mizer LT70 Series Specifications

General

Hydraulic Log Handling	Optional
Computer Setworks	Optional
Blade Width	1.5 inches (3.8 cm)
Power Options	Electric or diesel
Head Controls	Manual
Cutting Method	Horizontal bandsaw
