Wood-mizer LT70 Series User Manual

REPLACEMENT PARTS
Fuel System
3
3-15 doc072321 REPLACEMENT PARTS
3.9 Fuel System
REF. DESCRIPTION ( indicates parts available in assemblies only) PART # QTY
- FUEL SYSTEM 540680 1
1 PUMP, G57 FUEL 545997 1
2 VALVE, G57 PRESSURE SOLENOID 545998 1
3 KRÓCIEC 1 545999 2
4 KRÓCIEC 2 546000 1
5 WASHER, 6.4 FLAT ZINC F81053-1 4
6 NUT, M6-8-B HEX NYLON ZINC LOCK F81031-2 2
7 BOLT, M6X55-8.8 HEX HEAD ZINC F81001-73 2
8 CLAMP, UNI/52 M8-W1 HOSE 540679 2
9 WASHER, 8.4 FLAT ZINC F81054-1 4
10 NUT, M8-8-B HEX NYLON ZINC LOCK F81032-2 4
11 FITTING, FUEL PUMP 546001 1
12 FILTER, G57 FUEL 545996 1
13 FUEL HOSE 8MM, IV CARBUR /10-08 R80703-2 1
14 CLAMP, PLASTIC HOSE F81080-1 9

Wood-mizer LT70 Series Specifications

General

Hydraulic Log Handling	Optional
Computer Setworks	Optional
Blade Width	1.5 inches (3.8 cm)
Power Options	Electric or diesel
Head Controls	Manual
Cutting Method	Horizontal bandsaw
