Wood-mizer LT70 Series User Manual

Maintenance
Miscellaneous Maintenance
Maintenance G28doc072321 2-5
2
4. Loosen the mounting bolts (B) and locking bolt (C).
See Figure 2-2.
5. Using the adjustment bolt (D) set the alternator belt tension until the belt has 5 mm deflec-
tion with a 2.5 kg. deflection force. Re-tighten the locking nut.
6. Reinstall alternator belt cover.
2.8 Miscellaneous Maintenance
Clean and inspect the spark arresters every 50 hours of operation. Replace if damaged.
Inspect the spark plugs every 100 hours of operation. Remove any deposits and adjust
gap if necessary. See engine manual for further information.
CAUTION! Do not remove the plug wire to check for
electrical spark. Damage to the ignition circuit will result.
FIG. 2-2
B
C
D
50
100

Wood-mizer LT70 Series Specifications

General

Hydraulic Log Handling	Optional
Computer Setworks	Optional
Blade Width	1.5 inches (3.8 cm)
Power Options	Electric or diesel
Head Controls	Manual
Cutting Method	Horizontal bandsaw
