Wood-mizer LT70 Series User Manual

REPLACEMENT PARTS
How To Use The Parts List
3
3-1 doc072321 REPLACEMENT PARTS
SECTION 3 REPLACEMENT PARTS
3.1 How To Use The Parts List
 Use the index above to locate the assembly that contains the part you need.
 Go to the appropriate section and locate the part in the illustration.
 Use the number pointing to the part to locate the correct part number and descrip-
tion in the table.
 Parts shown indented under another part are included with that part.
 Parts marked with a diamond () are only available in the assembly listed above the
part.
See the sample table below. Sample Part #A01111 includes part F02222-2 and subas-
sembly A03333. Subassembly A03333 includes part S04444-4 and subassembly
K05555. The diamond (
) indicates that S04444-4 is not available except in subassembly
A03333. Subassembly K05555 includes parts M06666 and F07777-77. The diamond (
)
indicates M06666 is not available except in subassembly K05555.
To Order Parts:
 From Europe call our European Headquarters and Manufacturing Facility in Kolo,
Poland at +48-63-2626000. From the continental U.S., call our toll-free Parts hotline
at 1-800-525-8100. Have your customer number, vehicle identification number, and
part numbers ready when you call. From other international locations, contact the
Wood-Mizer distributor in your area for parts.
Office Hours:
CAUTION! It is strongly recommended that only original
spare parts be used.
3.2 Sample Assembly
REF. DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY
SAMPLE ASSEMBLY, COMPLETE (INCLUDES ALL INDENTED PARTS BELOW) A01111 1
7 Sample Part F02222-22 1
Sample Subassembly (Includes All Indented Parts Below) A03333 1
8 Sample Part ( Indicates Part Is Only Available With A03333) S04444-4 1 
Sample Subassembly (Includes All Indented Parts Below) K05555 1
9 Sample Part ( Indicates Part Is Only Available With K05555) M06666 2 
10 Sample Part F07777-77 1
Country Monday - Friday Saturday Sunday
POLAND 7-15 CLOSED CLOSED
US 8 A.M.- 5 P.M. 8 A.M. - 5 P. M. CLOSED

Wood-mizer LT70 Series Specifications

General

Hydraulic Log Handling	Optional
Computer Setworks	Optional
Blade Width	1.5 inches (3.8 cm)
Power Options	Electric or diesel
Head Controls	Manual
Cutting Method	Horizontal bandsaw
