Wood-mizer LT70 Series User Manual

2 D42doc072321 Table of Contents
Table of Contents Section-Page
SECTION 1 OPERATION 1-1
1.1 Starting the Engine .................................................................................1-1
1.2 HMI Display...........................................................................................1-5
1.3 Engine Specifications ...........................................................................1-11
SECTION 2 MAINTENANCE 2-1
2.1 Safety......................................................................................................2-1
2.2 Engine Oil & Filter.................................................................................2-2
2.3 Cooling System ......................................................................................2-2
2.4 Air Cleaner .............................................................................................2-2
2.5 Fuel Filter ...............................................................................................2-3
2.6 Battery ....................................................................................................2-3
2.7 Alternator Belt........................................................................................2-4
2.8 Miscellaneous Maintenance ...................................................................2-5
SECTION 3 REPLACEMENT PARTS 3-1
3.1 How To Use The Parts List ....................................................................3-1
3.2 Sample Assembly ...................................................................................3-1
3.3 G57 Engine Kit.......................................................................................3-2
3.4 G57 Engine Assembly .........................................................................3-4
3.5 Engine Bracket Set .................................................................................3-7
3.6 G57 Engine Alternator Assembly ..........................................................3-9
3.7 Exhaust System w/Mount.....................................................................3-11
3.8 Acceleration & Braking Mechanism....................................................3-13
3.9 Fuel System ..........................................................................................3-15
3.10 Battery Box...........................................................................................3-16
3.11 Engine Guards .....................................................................................3-18
3.12 Fuel Tank Assembly, LT70 - G57 .......................................................3-21
3.13 Control Box, LT70-G57 (Accuset 2) ..................................................3-23

Wood-mizer LT70 Series Specifications

General

Hydraulic Log Handling	Optional
Computer Setworks	Optional
Blade Width	1.5 inches (3.8 cm)
Power Options	Electric or diesel
Head Controls	Manual
Cutting Method	Horizontal bandsaw
