Wood-mizer LT70 Series User Manual

REPLACEMENT PARTS
Acceleration & Braking Mechanism
REPLACEMENT PARTS doc072321 3-14
3
19 PIN, PN-EN 22341-B-10 X32 X3,2 X26-ST-A2 F81047-1 1
20 PIN, PN-EN 22341-B-10X42X3.2X33-St-A2 ZINC-PLATED F81047-2 1
21 PIN, 3.2x25 COTTER F81043-4 2
22 WASHER, 8.4 FLAT ZINC F81054-1 6
23 NUT, M10-8-B HEX NYLON ZINC LOCK F81033-1 3
24 BOLT, M10X35-8.8 HEX HEAD FULL THREAD ZINC F81003-17 2
25 WASHER, 13 FLAT ZINC F81056-1 1
26 NUT, M12-8 HEX NYLON ZINC LOCK F81034-2 1
27 NUT, M8-8-B HEX NYLON ZINC LOCK F81032-2 5
28 GROMMET, 20/13 RUBBER 086188 1
29 WASHER, 6.4 FLAT ZINC F81053-1 3
30 BOLT, M6x12-8.8 HEX HEAD FULL THREAD ZINC F81001-7 3
31 BOLT, M10x1.25x25-8.8-A HEX HEAD FULL THREAD ZINC F81003-29 2
32 BOLT, M8X30-8.8-B HEX HEAD FULL THREAD ZINC F81002-7 2
33 BOLT, M8x25-8.8-B HEX HEAD FULL THREAD ZINC F81002-5 2
34 WASHER, 21 FLAT ZINC F81059-2 1
35 NUT, M20-6 HEX F81037-2 1
36 TURNBUCKLE, M10 096433-1 1
37 NUT, M10L-8-B HEX ZINC F81033-12 1
38 NUT, M10-8-B HEX ZINC F81033-3 1
- PLATE ASSEMBLY, BRAKE BLOCK 096438 1
39 PLATE, BRAKE BLOCK 096420-1 1
40 BLOCK, F9353 106 BRAKE NARROW 096432 6
41 SCREW, M5 x 25-8.8 HEX SOCKET HEAD CAP ZINC F81000-7 18
42 WASHER, 5.3 FLAT ZINC F81052-1 18
43 NUT, M5-8 DIN985 ZINC-PLATED F81030-2 18
44 WASHER, 8.4 FLAT ZINC F81054-1 8
45 NUT, M8-8-B HEX NYLON ZINC LOCK F81032-2 4
46 BOLT, M8x25-8.8-B HEX HEAD FULL THREAD ZINC F81002-5 4
47 COVER, ACTUATOR MOUNT BLOCK 096430-1 1
REF. DESCRIPTION ( indicates parts available in assemblies only) PART # QTY

Wood-mizer LT70 Series Specifications

General

Hydraulic Log Handling	Optional
Computer Setworks	Optional
Blade Width	1.5 inches (3.8 cm)
Power Options	Electric or diesel
Head Controls	Manual
Cutting Method	Horizontal bandsaw
