Wood-mizer LT70 Series User Manual

Operation
HMI Display
Operation G28doc072321 1-10
1
Language settings screen.
Use “-” and “+” buttons to set the language.
1. Back to the screen #2
2. Saves the selected language.
Engine error screen
1. Back to the screen #3
2. Toggle the errors stored in the controller memory.
Enter this screen if the EFI Diagnostic Indicator light is on. Note down the SPN and FMI
codes and pass this information to the Wood-Mizer Customer Service. When the EFI
FIG. 1-8
FIG. 1-9
1
2
1
2

Wood-mizer LT70 Series Specifications

General

Hydraulic Log Handling	Optional
Computer Setworks	Optional
Blade Width	1.5 inches (3.8 cm)
Power Options	Electric or diesel
Head Controls	Manual
Cutting Method	Horizontal bandsaw
