Wood-mizer LT70 Series User Manual

REPLACEMENT PARTS
G57 Engine Kit
3
3-3 doc072321 REPLACEMENT PARTS
14 WASHER, 10.5 FLAT ZINC F81055-1 4
15 WASHER, 10.2 SPLIT LOCK ZINC F81055-2 4
16 SCREW, M10 X 25 8.8 HEX SOCKET HEAD CAP ZINC F81003-32 4
17 SWITCH, AZ17-11ZRK SAFETY 094232 2
18 SCREW, M4x35-8.8 HEX SOCKET HEAD CAP ZINC F81011-34 4
19 WASHER, 4.3 FLAT ZINC F81051-2 4
20 KEY, A217/170-B5 SAFETY SWITCH 094422 2
21 SCREW, M4x12 5.8-B CROSS RECESSED PAN HEAD ZINC F81011-43 4
22 NUT, M4-B HEX NYLON ZINC LOCK F81029-1 8
23 TANK ASSEMBLY, LT70/G57 FUEL See Section 3.12
540678 1
24 CONTROL BOX, LT70-G57 (FOR ACCUSET) See Section 3.13
543535 1
25 GROMMET, RUBBER 087065 1
26 BOX, BATTERY COMPLETE See Section 3.10
089794 1
27 BRACKET, SAFETY SWITCH RELAY 096873-1 1
28 RELAY, SAFETY SWITCH 086486 1
29 BRACKET ASSEMBLY, RADIATOR UPPER See Section 3.11
545965 1
30 GUARD ASSEMBLY, DRIVE BELT See Section 3.11
545981 1
31 GUARD ASSEMBLY, SIDE See Section 3.11
545970 1
32 GUARD ASSEMBLY, MUFFLER See Section 3.11
545975 1
33 GUARD, FUEL SYSTEM - COMPLETE See Section 3.11
545983 1
- BRACKET, CROSS - COMPLETE 546511 1
34 BRACKET, CROSS 546510-1 1
35 WASHER, 6.4 FLAT ZINC F81053-1 4
36 NUT, M6-8-B HEX NYLON ZINC LOCK F81031-2 2
37 BOLT, M6 x 16 8.8 HEX HEAD FULL THREAD ZINC F81001-15 2
REF. DESCRIPTION ( indicates parts available in assemblies only) PART # QTY

Wood-mizer LT70 Series Specifications

General

Hydraulic Log Handling	Optional
Computer Setworks	Optional
Blade Width	1.5 inches (3.8 cm)
Power Options	Electric or diesel
Head Controls	Manual
Cutting Method	Horizontal bandsaw
