REPLACEMENT PARTS
G57 Engine Assembly
3
3-5 doc072321 REPLACEMENT PARTS
Filter, Oil #W21ESO1600 097743 1
2 RADIATOR, G57 545985 1
Cushion, Rubber Kubota Engine Radiator, upper, #15111-7219 5588071
Cushion, Rubber Kubota Engine Radiator, lower, #15111-7218 5588081
- SHAFT ASSEMBLY, G57 ENGINE OUTPUT 540658 1
3 SHAFT, KUBOTA ENGINE OUTPUT 088732 1
4 KEY, A10X8X63 PARALLEL 088130 1
5 WASHER, 10.2 SPLIT LOCK ZINC F81055-2 6
6 BOLT, M10x1.25x25-8.8-A HEX HEAD FULL THREAD ZINC F81003-29 6
7 CLUTCH, CENTRIFUGAL 160.236Nm 089467 1
8 WASHER, BLADE DRIVE WHEEL 088956-1 1
9 WASHER, 10.2 SPLIT LOCK ZINC F81055-2 1
10 BOLT, M10 X 25 8.8 HEX HEAD FULL THREAD ZINC F81003-31 1
11 BRACKET SET, ENGINE See Section 3.5
543518 1
12 ALTERNATOR ASSEMBLY, G57 See Section 3.6
540649 1
- FILTER ASSEMBLY, AIR 540650 1
13 BRACKET, AIR FILTER 540653-1 1
14 WASHER, 6.4 FLAT ZINC F81053-1 2
15 WASHER, Z 6.1 SPLIT LOCK ZINC F81053-3 2
16 BOLT, M6 x 16 8.8 HEX HEAD FULL THREAD ZINC F81001-15 2
17 FILTER, G57 AIR 545986 1
Filter, D22/D33 Kubota Air Outer 097692 1
Filter, D22/D33 Kubota Air Inner 097693 1
18 HOSE, RUBBER 545991 1
19 T-CONNECTOR 545987 1
20 HOSE, 12.5 L. 500 MM 540654 1
21 CLAMP, 70-80 MM F81095-5 2
22 CLAMP, 11-17 MM HOSE F81080-3 2
23 EXHAUST SYSTEM W/MOUNT - COMPLETE See Section 3.7
540645 1
24 ACCELERATION & BRAKE ASSEMBLY, LT70 G57 See Section 3.8
540677 1
- HOSE, D42 OIL DRAIN 091774 1
25 HOSE, OIL DRAIN 091777 1
26 End, BANJO M22x1.5x1/2 ZMB 600-22-08 091773 1
27 WASHER, 22 COPPER F81061-5 2
28 Bolt, BANJO M22x1.5 ZMB 610-22/1.5 091772 1
29 CLAMP, 11-17 MM HOSE F81080-3 1
30 CLIP, RSGU 1.20/20 METAL & RUBBER RETAINING F81087-2 1
31 BRACKET, OIL DRAIN HOSE 092516-1 1
32 WASHER, 8.4 FLAT ZINC F81054-1 2
33 BOLT, M8x25-8.8-B HEX HEAD FULL THREAD ZINC F81002-5 1
34 NUT, M8-8-B HEX NYLON ZINC LOCK F81032-2 1
35 FITTING, 3/4 UNF 094740_ 1
REF. DESCRIPTION ( indicates parts available in assemblies only) PART # QTY
