Wood-mizer LT70 Series User Manual

REPLACEMENT PARTS
Engine Guards
3
3-19 doc072321 REPLACEMENT PARTS
6 WASHER, 8.4 FLAT ZINC F81054-1 8
7 BOLT, M8x20-8.8-B HEX HEAD FULL THREAD ZINC F81002-4 4
- GUARD ASSEMBLY, DRIVE BELT 545981 1
8 PLATE WELDMENT, FRONT GUARD 545978-1 1
9 PLATE WELDMENT, SIDE GUARD 545979-1 1
10 WASHER 545971-1 1
11 WASHER, 6.4 FLAT ZINC F81053-1 1
12 WASHER, 6.5 SPECIAL FLAT ZINC F81053-11 6
13 WASHER, 8.5 SPECIAL FLAT ZINC F81054-11 1
14 WASHER, 8.2 SPLIT LOCK ZINC F81054-4 1
15 WASHER, Z 6.1 SPLIT LOCK ZINC F81053-3 9
16 BOLT, M6x12-8.8 HEX HEAD FULL THREAD ZINC F81001-7 7
17 BOLT, M6 x 16 8.8 HEX HEAD FULL THREAD ZINC F81001-15 2
18 BOLT, M8x16-8.8-B HEX HEAD FULL THREAD ZINC F81002-20 1
19 CLIP, RSGU 1.10/12W1 METAL & RUBBER RETAINING 086861 2
20 WASHER, 5.3 FLAT ZINC F81052-1 2
21 NUT, M5-8 DIN985 ZINC-PLATED F81030-2 1
22 BOLT, M6X20 HH FT ZC 8.8 DIN 933 ISO 4017 F81000-35 1
23 WASHER, 8.4 FLAT ZINC F81054-1 2
24 CLIP, RSGU 1.15/20 METAL & RUBBER RETAINING 509701 1
25 NUT, M8-8-B HEX NYLON ZINC LOCK F81032-2 1
26 BOLT, M8x25-8.8-B HEX HEAD FULL THREAD ZINC F81002-5 1
- GUARD ASSEMBLY, SIDE 545970 1
27 GUARD WELDMENT, RIGHT 545969-1 1
28 GUARD WELDMENT, RIGHT 545957-1 1
29 GUARD WELDMENT, LEFT 545959-1 1
30 WASHER, 6.5 SPECIAL FLAT ZINC F81053-11 15
31 WASHER, Z 6.1 SPLIT LOCK ZINC F81053-3 15
32 WASHER, 8.5 SPECIAL FLAT ZINC F81054-11 1
33 WASHER, 8.2 SPLIT LOCK ZINC F81054-4 1
34 BOLT, M6x12-8.8 HEX HEAD FULL THREAD ZINC F81001-7 15
35 BOLT, M8x16 -8.8-B HEX HEAD FULL THREAD ZINC F81002-20 1
- GUARD ASSEMBLY, MUFFLER 545975 1
36 GUARD, MUFFLER UPPER 545974-1 1
37 PLATE WELDMENT, MUFFLER GUARD LOWER 545973-1 1
38 WASHER, 6.4 FLAT ZINC F81053-1 10
39 WASHER, 6.5 SPECIAL FLAT ZINC F81053-11 6
40 WASHER, Z 6.1 SPLIT LOCK ZINC F81053-3 16
41 BOLT, M6x12-8.8 HEX HEAD FULL THREAD ZINC F81001-7 16
- GUARD, FUEL SYSTEM - COMPLETE 545983 1
42 GUARD, FUEL SYSTEM 545982-1 1
43 WASHER, 6.5 SPECIAL FLAT ZINC F81053-11 4
REF. DESCRIPTION ( indicates parts available in assemblies only) PART # QTY
