Worlde W8807A - Preparations and Connections; Setting Up the Keyboard

PREPARATIONS
8
Setting Up Setting Up
1.Fix the left and right feet on the ground board with 4 black screws at each side.
2.Fix the left and right feet on the front panel with 4 black screws at each side.
3.Place the body onto the plank, and fix it with 4 zinc-gilded screws at each side as
shows in the illustration.
4.Connect the cable of foot switch with the plug cable (As shown in the illustration).
5.Move the screw between the sustain pedal and damper pedal right onto the ground,
in order to pin up the pedal.
1
2
4
3
5
