Multi 197i Operation
55
ba75339e04 07/2009
4.8 Transmitting data
You have the following possibilities of transmitting data:
z One of the following options:
– With the AutoStore function (page 46), the measured values of all
connected and active sensors are stored periodically and output
to the interface (save interval Int 1).
–With the Data transmission interval (Int 2), the measured values
of all connected and active sensors are periodically output to the
interface (see below).
– AutoStore (Int 1) covers the Data transmission interval
(Int 2).
z Press the <RUN/ENTER> key
This manually triggers a data transmission of the current measured
value to the serial interface at any time - independently of the select-
ed intervals.
z With the Output data storage function (page 48), calibration data or
saved measured values are output on the interface.
4.8.1 Data transmission interval (Int 2)
The interval for the data transmission (Int 2) determines the chronolog-
ical interval between automatic data transmissions. After the selected
interval expires, the current data record is transmitted to the interface.
Setting the
Data transmission
interval
The default setting for the interval is OFF.
To start the data transmission, set an interval (5 s, 10 s, 30 s, 1 min,
5 min, 10 min, 15 min, 30 min, 60 min):
1 Press the <RUN/ENTER> key and hold it down.
2 Press the <RCL> key. Int 2 appears on the display.
3 Set the required interval between the saving procedures with
<▲> <▼>.
