pH 3310 Operation
17
ba75802e02 12/2008
4.2.2 Navigation
Measured value display In the measured value display, you can
z open the respective measuring menu with <F1> (short
keystroke).
z open the Storage & config menu with the sensor-independent
settings by pressing <F1
_> (long keystroke, approx. 2 s on <F1>).
z change the display in the selected measuring window
(e. g. pH <−> mV) by pressing <M>.
Menus and dialogs The menus for settings and dialogs in procedures contain further
submenus. The selection is made with the <▲><▼> keys. The current
selection is displayed with a frame.
z Submenus
The name of the submenu is displayed at the upper edge of the
frame. Submenus are opened by confirming with <ENTER>.
Example:
z Settings
Settings are indicated by a colon. The current setting is displayed on
the right-hand side. The setting mode is opened with <ENTER>.
Subsequently, the setting can be changed with <▲><▼> and
<ENTER>. Example:
