Overview pH 3310
8
ba75802e02 12/2008
1.3 Socket field
Caution
Only connect sensors to the meter that cannot return any voltages
or currents that are not allowed (> SELV and > current circuit with
current limiting).
Almost all customary sensors fulfill these conditions.
Connectors:
1 pH electrode
2 Reference electrode
3 Temperature sensor
4 USB B (device) interface
5 Service interface
5
1
2
3
4
