X-Rite Ci62L+RTL User Manual

CI62L+RTL SPECTROPHOTOMETER
27
7. Select a project (if required).
8. Select the standard that will be used for the sample measurement.
9. Position the instrument on the first area of the sample and take a measurement. After the
measurement, the instrument displays "Averaged 1 of 3" in the screen, indicating two more
measurements are required for results.
10. Position the instrument on the second area of the sample and take a measurement. After the
measurement, the instrument displays "Averaged 2 of 3" in the screen, indicating one more
measurement is required for results.
11. Position the instrument on the third area of the sample and take a measurement. After the
measurement, the instrument momentarily displays "Processing" and then the averaged
sample data values and difference values.
Measurement Mode icon
Current standard and
project selected
