Trouble
sh
ooting
Xerox
®
WorkCentre
®
7220/7220i/7225/7225i Co
lor Multifunc
tion Printer
237
User G
uid
e
Clearing
Jams
at D
oor A
1.
Open tray 5 an
d door A.
2.
Remove the ja
mmed paper.
3.
Open t
he
fuser by pull
ing out the handle la
beled A1.
WARNING:
The area aro
und the fuser can be hot. U
se caution to avoi
d injury.
4.
Remove the jammed paper
.
236
238
