239
User G
uid
e
3.
Remove the ja
mmed paper.
4.
Close door D, then close tray 5.
Clear
ing Jams i
n the Do
cument Feed
er
1.
Lift the lever and o
pen the top cover of the
document feeder as
shown.
2.
If the original is not caught in the entry
to the document feeder, pull it straight out in the direction
shown
.
238
240
