4. Power on the printer.
For details on configuring network settings, refer to the System Administrator Guide at www.
xerox.com/office/B1022_B1025docs.
5. Enter the printer IP address, or set Xerox
®
CentreWare
®
Internet Services to discover the network
IP address of the printer automatically.
CCoonnnneeccttiinngg tthhee PPrriinntteerr ttoo aa WWiirreelleessss NNeettwwoorrkk
If you purchased a Wireless Network Adapter, you can connect the device to a wireless network. If
the device is connected to a wired network, you can configure wireless settings using Xerox
®
CentreWare
®
Internet Services. For details on configuring wireless network settings, refer to the
System Administrator Guide at www.xerox.com/office/B1022_B1025docs.
Note: Before configuring wireless network settings, install the Xerox Wireless Network Adapter
Kit. For information, refer to the Hardware Install and Setup instructions that are included with
the kit.
CCoonnnneeccttiinngg ttoo aa CCoommppuutteerr UUssiinngg UUSSBB
To connect using USB, you need Windows 7, Windows 8 or later, Windows Server 2008 or later, or
Macintosh OS X version 10.9 or later.
To connect the printer to the computer using a USB cable:
1. Connect the B end of a standard A/B USB 2.0 cable to the USB Port on the rear left of the printer.
2. Connect the A end of the USB cable to the USB port on the computer.
3. If the Windows Found New Hardware Wizard appears, select Cancel.
4. Install the print drivers. For details, refer to Installing the Driver Software.
CCoonnnneeccttiinngg ttoo aa TTeelleepphhoonnee LLiinnee
Note: Not all options listed are supported on all printers. Some options apply only to a specific
printer model, configuration, operating system, or driver type.
1. Connect a standard RJ11 cable, No. 26 American Wire Gauge (AWG) or larger, to the Line port on
the back of the printer.
2. Connect the other end of the RJ11 cable to an operating telephone line.
3. Enable and configure the Fax functions.
For details, refer to the System Administrator Guide at www.xerox.com/office/B1022_B1025docs.
Xerox
®
B1025 Multifunction Printer
User Guide
33
Getting Started

Xerox B1025 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Booklet printing function	Yes
Print speed (black, normal quality, A4/US Letter)	25 ppm
Duplex print speed (black, normal quality, A4/US Letter)	13 ppm
PCL fonts	107
Printer fonts	PCL, PostScript
Digital sender	-
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2000 - 50000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 6, PostScript
Compatible memory cards	MicroSD (TransFlash)
Maximum internal memory	1536 MB
Sound pressure level (quiet mode)	30 dB
Wi-Fi	No
Security features	Firmware Verification, Security Certificate Management, Signed Certificate Creation, Audit Log
Cabling technology	10/100Base-T(X)
Security algorithms	AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	110 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (off)	2 W
Power consumption (sleep)	1.5 W
Power consumption (average operating)	650 W
Energy Star Typical Electricity Consumption (TEC)	1.65 kWh/week
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	750 mm
Package width	771 mm
Package height	600 mm
Package weight	32300 g
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Scan speed (color)	30 ppm
Image formats supported	JPEG, TIFF
Document formats supported	PDF
Optical scanning resolution	600 x 600 DPI
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Other operating systems supported	Solaris 11
Mobile operating systems supported	Android
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Copier resize	25 - 400 %
Time to first copy (black, normal)	7.6 s
Copy speed (black, normal quality, A4)	25 cpm
Modem speed	33.6 Kbit/s
Total input capacity	100 sheets
Total output capacity	250 sheets
Product color	Black, White
Market positioning	Business
Paper tray media types	Bond paper, Heavy paper, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper, Thin paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3

Weight and Dimensions

Depth	555.3 mm
Width	560 mm
Height	417 mm
