Printer installation 1. Setting up the DocuColor 2006
Xerox DocuColor 2006 1-23
If lever B will not move to the Locked position, ensure that the cartridge is all
the way into the Printer.
g. Rotate lever A in the direction of the arrow until the dot is aligned
with the Locked symbol.
301039b
5. Install the Dry Ink Cartridges:
Each Dry Ink Cartridge chamber is designated by a specific color. Ensure
that the correct Dry Ink Cartridge is installed into the corresponding color on
the chamber.
The Dry Ink box and packing can be used to ship old cartridges back to your
supplier for recycling.
a. Locate the correct Dry Ink Cartridge box for the color of the current
chamber.
b. Remove the Dry Ink Cartridge from the box.
c. Shake the cartridge seven or eight times as shown below.
301040A-WO
0
301040a
