Installing the Sorter/Stacker 1. Setting up the DocuColor 2006
Xerox DocuColor 2006 1-61
CAUTION
Do not remove the plastic tie wrap on the metal roller under the jam
clearance cover. The tie wrap holds a sensor wire out of the way, as
illustrated in the figure below.
10. Remove the tape that is holding the connector cord in place. Keep the
cord wrapped to protect the connector.
11. Ensure that any remaining tape is removed from the unit.
