Xerox CopyCentre C20, WorkCentre M20 and WorkCentre M20i User Guide Page 10-9
Maintenance
z The toner
cartridge must be
removed to
replace the drum
cartridge.
3
¾ Turn the cartridge locking lever
upwards to release the toner
cartridge.
4
¾ Pull out the used drum cartridge.
5
¾ Unpack the new drum cartridge
and slide it in place, making sure
not to touch the surface of the
drum.
