Xerox DocuMate 3920
User’s Guide
119
5. Place your fingertip under the top edge of the traction pad and pull up. The traction pad is held in
place by two tabs on the underside of the pad, you will hear a “click” when it releases from the
scanner.
6. Place the new traction pad in the scanner. Align the tabs on the bottom of the traction pad with
the slots in the scanner. Press down on the pad to snap the part into the scanner.
7. Place the new tension spring in the slot in the scanner.
Slots for the
traction pad
Tension
spring slot
