Xerox DocuMate 3920
User’s Guide
15
Connecting the Cables
Connecting the Power Cable
1. Press the power switch to the “O” position to turn off the scanner.
2. Plug the power supply into the power jack on the scanner.
NOTE: Only use the power supply (HEG75-S240320-7L made by HiTron) included with your scanner.
Connecting any other type of power supply may damage your scanner, and will void its warranty.
3. Plug the power cord into the power supply and into a wall outlet.
Connecting the Ethernet Cable
1. Connect one end to the LAN port at the back of the scanner.
2. Connect the other end of your Ethernet LAN cable to an available port on your Ethernet Hub or
wall.
Connecting the Telephone Line
1. Plug one end of the telephone line to the LINE jack at the right end of the rear panel.
