Xerox DocuMate 4790 User Manual

Xerox DocuMate 4790
User’s Guide
168
5. Insert the right side of the roller module into the scanner, then carefully angle the left of the roller
module into the scanner. Be careful while inserting the roller module as the gears will engage as
you place the module in the scanner.
6. Gently lift and hold the roller module in the scanner and then rotate the locking arm up and into
the scanner. Make sure the roller module is securely in place before closing the scanner.
Replacing the Double Feed Prevention Roller
1. Pull up on the double feed prevention roller cover and remove it from the scanner. Set the cover
aside and make sure nothing is set on the cover as it will break.

Xerox DocuMate 4790 Specifications

General

Film scanning	No
Color scanning	Yes
Duplex scanning	-
Input color depth	24 bit
Maximum scan size	297 x 432 mm
Enhanced scan resolution	300 x 300 DPI
Optical scanning resolution	600 x 600 DPI
Display	LCD
Scanner type	Flatbed & ADF scanner
Product color	Blue, White
Sensor type	CCD
Daily duty cycle (max)	10000 pages
Auto document feeder (ADF) input capacity	200 sheets
Minimum scan area (ADF)	48 x 70 mm
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	75 - 80 g/m²
USB version	2.0
Standard interfaces	USB 2.0
Minimum RAM	2048 MB
Minimum processor	Intel® Pentium® 4
Minimum storage drive space	350 MB
Compatible operating systems	Windows 7 Windows Vista Windows XP
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	444 mm
Width	468 mm
Height	339 mm
Weight	18000 g
