70 I-Class
Standard Calibration (continued)
Step Operator Action Displayed Message Comment
9
Observe the display.
Or, for reflective media:
Or, for continuous media:
The calibration
was successful.
See note below if
another message
was displayed.
10
Exit upon successful
calibration: Back out of
the menu tree by
repeatedly pressing the
Key.
If using gap or reflective
media, press and hold
the FEED Key. The
printer will begin
advancing media; allow
at least one label gap (or
mark) to advance under
the sensor.
The printer is now
ready to begin
printing.
If this calibration
was unsuccessful,
go to Section 5.0.2.
þ Note: A ‘Warning Low Backing’ message indicates that the calibration was
successful with notched media or media on a transparent liner; see
Section 6.1 for details on this and other possible messages.
To Next Page
