June 2014
2-8
Xerox® Phaser® 3052/3260 Service Manual
07-500 , 07-530
Status Indicator RAPs
07-500 Manual Feed Slot Paper Empty Fault
The Registration Sensor failed to detect paper in the Manual Feed Slot.
BSD-Reference: 7.1 Paper Feed and Registration
Initial Actions
Ensure that paper is loaded in the tray. Clear any jammed sheets. Refer to Section 7: Trouble-
shooting, in the Xerox® Phaser® 3052/3260 User Guide for detailed instructions on clearing
paper jams.
Procedure
Check the Registration Sensor actuator. The actuator moves freely and is undamaged.
YN
Check that no contamination is present.
Replace the Registration Sensor Actuator (REP 1.14), PL 4.4.
Enter Diagnostics (EDC) Mode [DC330 Test Routines, 102-Sensor, Registration Sensor]. to
block and clear the Registration Sensor. The sensor signal changes.
YN
Check for 3.3 VDC on the Main PWB. The voltage is present on the Main PWB.
YN
Replace the HVPS PWB (REP 1.7), PL 4.1.
Replace the Main PWB (REP 1.8), PL 1.1.
Replace the Feed Sensor PWB (REP 1.14), PL 4.4.
Perform SCP Final Actions.
07-530 Paper Feed Fault - Manual Feed Slot
The lead edge was not detected by the Paper Feed Sensor.
BSD-Reference: 7.1 Paper Feed and Registration
Initial Actions
Clear any jammed sheets. Refer to Section 7: Troubleshooting, in the Xerox® Phaser® 3052/
3260 User Guide for detailed instructions on clearing paper jams.
Procedure
Check the position of the jammed sheet. The lead edge reached the Retard Roll.
YN
Enter Diagnostic (EDC) Mode. Select: [DC330 Test Routines, 102-Sensor, Feed Sens]
to block and clear the Paper Feed Sensor. The sensor is OK.
YN
Check for an open or short circuit.
Replace the Feed Sensor (REP 1.14), PL 4.4.
In Diagnostic Mode, select: [101-Clutch, Registration] to engage the drive to pick up
paper from tray 1. The clutch engages.
YN
Check for an open or short circuit.
Replace the Tray 1 Pick up (Feed) Clutch (REP 1.13), PL 4.1.
Perform SCP Final Actions.
Check the Paper Feed actuator. The actuator moves freely and is undamaged.
YN
Replace the Paper Feed actuator, (REP 1.14), PL 4.4.
Inspect the Paper Feed Sensor for damage. The sensor is OK.
YN
Check for an open or short circuit.
Replace the Paper Feed Sensor PWB (REP 1.14), PL 4.4.
Check the circuit of the Paper Feed PWB.
