General Care and Troubleshooting
Xerox Phaser 4600/4620
User Guide
100
3. Close the High Capacity Feeder door.
Top Cover Areas
There is a jam at the exit or at the rear cover. The control panel will specify a fault has occurred. When
the Error screen is displayed, press OK for further information. If the Error screen is not visible, press the
Back button to access the Error screen.
1. Open the top cover and remove the Toner Cartridge.
2. Remove the Drum Cartridge.
3. Lift baffle by green handle and gently pull the jammed paper
out of the rollers.
4. If you cannot move the jammed paper, pull Tray 2
completely out of the printer.
5. Replace the tray.
6. Insert the Drum Cartridge and the Toner Cartridge and close
the top cover.
