Xerox Phaser 5335 User Manual

7.9 Cleaning the Printer 175
6. Wipe the rubber part of both feed rolls
thoroughly with a soft, damp cloth
moistened with water.
7. After cleaning the feed rolls, reinstall them
in the printer. Place one of the feed rolls on
the back shaft from the side with the short
tab first.
8. Align the short tab of the feed roll with the
indentation on the shaft, and push the feed
roll firmly onto the shaft.
9. Place other feed roll back on the front shaft
in the same manner.
10. Push the tray all the way into the printer.
Important
• When inserting the tray, be careful not to get your
fingers caught between the tray and the printer or
another tray (if the optional sheet feeders are
installed).
long tab
short tab
