Xerox Phaser 7400

Parts of the Printer
Phaser® 7400 Color Printer
1-4
Internal Components
1. Imaging Unit basket handle
2. Fuser
3. LED bars
4. Toner Cartridges and Imaging Units (Cyan, Magenta, Yellow, and Black)
5. Toner Cartridge
6. Imaging Unit
1. Imaging Unit basket (lifted)
2. Transfer Unit
3
2
4
5
6
7400-003
1
1
2
7400-004
