3.
Caution: Do not expose the drum cartridge to direct sunlight or strong indoor fluorescent
lighting. Do not touch or scratch the green surface of the Drum Cartridge.
To remove the Drum Cartridge, grip the orange handle, then pull the Drum Cartridge straight out
of the printer. Place the removed Drum Cartridge on a clean, level surface.
4. Remove the cleaning tool from inside the Front Door.
5. Remove the cleaning pad from the cleaning tool by pushing in on the two tabs. Properly recycle
the used cleaning pad.
Note: If the cleaning pad is dirty, replace it. A replacement cleaning pad is included
with the Drum Cartridge Replacement Kit.
Xerox
®
VersaLink
®
B605/B615 Multifunction Printer
User Guide
181
Maintenance
