Xerox® WorkCentre® 3025 Multifunction Printer Service Manual
01-100 , 03-410
Status Indicator RAPs
01-100 Top Cover Open Fault
The Front cover is open or the cover open switch is defective.
BSD-Reference: 1.1 AC/Low Voltage and High Voltage Power / Interlocks
Initial Actions
Ensure that the Front cover is completely closed.
Procedure
WARNING
Do not perform repair activities with the power on or electrical power supplied to the
machine. The machine could activate and cause serious personal injury when the power
is on or electrical power is supplied.
DANGER: Ne pas effectuer de dépannage avec le contact principal activé ou avec l'ali-
mentation électrique appliquée à la machine: celle-ci pourrait démarrer et causer de
graves blessures.
AVVERTENZA: Non effettuare alcuna riparazione con la macchina accesa o con l'ali-
mentazione elettrica inserita. La macchina potrebbe avviarsi all'improvviso e causare
gravi ferite.
VORSICHT: Es dürfen keine Reparaturarbeiten durchgeführt werden, solange das Gerät
eingeschalten oder mit der Stromquelle verbunden ist. Das Gerät kann u.U in den Aktiv-
Zustand übergehen und somit erhebliche körperliche Schäden verursachen.
AVISO: No realice reparaciones con la máquina encendida o conectada a la corriente. La
máquina podría activarse y ocasionar daños personales graves.
Check the Top Cover Open Switch Actuator for binding or damage. The Actuator moves
freely.
YN
Replace the LVPS/HVPS PWB (REP 1.5), PL 5.1.
Check the connection between the Main PWB and the HVPS. The connection is secure.
YN
• Check that there is no contamination present.
• Check for broken or defective wires or cables.
• Replace the Main PWB (REP 1.7), PL 1.1.
Replace the LVPS/HVPS PWB (REP 1.5), PL 5.1.
03-410 Paper Mismatch at Tray 1
The size setting for the Paper Tray does not match the paper size loaded in the tray.
BSD-Reference: 7.1 Paper Feed and Registration
Initial Actions
• Check the media size settings for the tray from the Control Panel.
• Adjust the Paper Tray Guides to match the size of the paper that is loaded into the tray.
• Place the correct size paper into the tray for the tray size setting.
Procedure
1. Switch Off the power then switch On the power.
2. If problem continues, replace the Main PWB (REP 1.7) , PL 1.1.
