June 2014
2-6
Xerox® WorkCentre® 3025 Multifunction Printer Service Manual
06-100 / 200 , 07-110
Status Indicator RAPs
Enter Diagnostic (EDC) Mode. Select: [DC330 Component Control, 110 LSU, LSU Mot1
Run] to test the LSU motor. The motor runs.
YN
Check the Main Wire Harness and connectors between the Laser Module and the Main
PWB. The connections are secure.
YN
Check that the connectors are secure and no contamination is present.
Disconnect and securely reconnect the harness.
Check the harness for a short circuit or open circuit (BSD 6.1). The harness is OK.
YN
Check that the connectors are secure and no contamination is present.
Replace the harness (REP 1.21), PL 5.6.
Replace the Laser Module. (REP 1.12), PL 5.6.
Go to [SCP 04] Final Actions.
07-110 Paper Jam or Tray Empty Fault
The Tray Empty Sensor failed to detect paper in the tray.
BSD-Reference: 7.1 Paper Feed and Registration
Initial Actions
Ensure that paper is loaded in the tray. Clear any jammed sheets. Refer to Section 7: Trouble-
shooting, in the Xerox® WorkCentre® 3025 User Guide for detailed instructions on clearing
paper jams.
Procedure
Check the actuators for the Feed and Width Sensors. The actuators move freely and are
undamaged.
YN
Replace the Feed or Width Sensor actuator, (REP 1.15), PL 5.3.
Enter Diagnostic(EDC) Mode. Select: [DC330 Component Control, 102 Sensor, Feed Sen-
sor. Actuate and deactuate the Feed Sensor. The sensor signal changes.
YN
1. Check that there is no contamination present.
2. Check the circuit between the Paper Feed PWB and the Main PWB for an open or
short circuit.
3. Replace parts as required.
If the problem is intermittent, check the circuit of the Feed Sensor PWB.
