Xerox WORKCENTRE 7120 System Administrator Guide

Administrator Tools
WorkCentre 7120/7125 Multifunction Printer
System Administrator Guide
148
Address Books
If your network is connected to an LDAP server you can configure the printer to look up addresses from
the LDAP directory. For details, see LDAP on page 33. If you do not have an LDAP server, you can use
the Fax Address Book and the Public Address Book to store fax machine phone numbers and email
addresses on the printer.
The printer can be configured to access both an LDAP directory and a Public Address Book. If both are
configured, users will be presented with the choice to use either address book.
Public Address Book
Email addresses, internet fax addresses, and fax numbers are stored in the Public Address book.
Note: An Internet Fax Address is the email address of an Internet fax machine.
Editing the Public Address Book as a .csv File
If you have many addresses to manage, you can create a list of addresses in a spreadsheet application,
save it as a .csv file, and upload it to the printer.
Format
The address book file must be in comma separated format (.csv). The printer recognizes the second row
in the .csv file as the first data entry. The first row contains headings for the data in each column. The
default column heading names are: Name, Email Address, Internet Fax Address.
Example:
To download a sample .csv file:
1. In CentreWare IS, click the Address Book tab.
2. Under Management, click Download Sample.
3. Click Download in CSV format. Save the file to your computer.
To download a.csv file with headings only (no sample data):
1. In CentreWare IS, click the Address Book tab.
2. Under Management, click Export File with Column Heading only.
3. Click Download in CSV format. Save the file to your computer.
Name Email Address Fax Number Internet Fax Address
Jim Smith jim.smith@corp.com 1234567898 faxmachine.one@corp.com
Ellen Jones ellen.jones@corp.com 4566544985 faxmachine.two@corp.com
Richard Allen richard.allen@corp.com 7899855546 faxmachine.three@corp.com

Xerox WORKCENTRE 7120 Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	13 s
Time to first page (color, normal)	11 s
Print speed (black, normal quality, A3)	11 ppm
Print speed (black, normal quality, A4/US Letter)	20 ppm
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Page description languages	PCL 6, TIFF
Maximum scan area	216 x 279 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.5 s
Scan file formats	PDF, XPS
Weight (imperial)	251 lbs
Custom media sizes	5.5''x 7.2'' - 11.7''x 17''
Dimensions (WxDxH)	585 x 640 x 1132 mm
Power requirements	100 - 240V, 50/60Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	148 x 210mm - 297 x 420mm
Media weight (tray 2)	60 - 256 gsm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows XP SP1 32/64-bit Windows Server 2003 32/64-bit Windows Server 2008 32/64-bit Windows Vista 32/64-bit Windows 7 32/64-bit Mac OS v10.4+ AIX 5 v5.3 HP UX 11.0, 11i v2 Solaris 8, 9, 10 Linux FedoraCore 1, 5 RedHat Enterprise Linux 4 SUSE 10/11
Dimensions (W x D x H) (imperial)	23 x 25.2 x 44.6 \
Total input capacity	520 sheets
Total output capacity	250 sheets
Maximum input capacity	2130 sheets
Total number of input trays	5
Auto document feeder (ADF) input capacity	110 sheets
Internal storage capacity	80 GB
Sound power level (standby)	16 dB
Sound pressure level (printing)	52 dB
Display	-
Market positioning	Business
Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Supported network protocols (IPv4)	SMTP, S/MIME, POP3, HTTP/HTTPS, LPR/LPD, IPv4/IPv6, Bindery, NDS IPX/SPX, NDPS/NEPS, EtherTalk, NetBEUI, MVNoIP
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	119 W
Power consumption (average operating)	578 W
Sustainability certificates	ENERGY STAR
Certification	FCC, CB, ISO
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
