Xerox WorkCentre 7225 User Manual

Maintenance
Xerox
®
WorkCentre
®
7220/7220i/7225/7225i Color Multifunction Printer 193
User Guide
2. To remove fingerprints and smudges, clean the touch screen and control panel with a soft, lint-free
cloth.
3. To return the printer to Ready mode, press the Energy Saver button.
4. Use a soft, lint-free cloth to clean the outside of the output tray, paper trays, and other exterior
areas of your printer.
Cleaning the Printer Interior
Cleaning the Laser Windows
The printer is constructed with four laser windows and a laser window cleaning wand to remove toner
dust from them.
CAUTIONS:
• Do not perform this procedure when the printer is copying or printing.
• To prevent a printer malfunction or damage to the internal hard drive, turn off the
secondary power switch. Wait 10 seconds after the touch screen goes dark, then turn
off the main power switch.

Xerox WorkCentre 7225 Specifications

General

Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Duplex Printing	Standard
Functions	Print, Copy, Scan, Fax
Memory	2 GB
Fax Speed	33.6 Kbps
Print Speed	Up to 25 ppm
Connectivity	10/100/1000Base-T Ethernet, USB 2.0
Hard Drive	160 GB
Operating System Compatibility	Windows, Mac OS, Linux
Dimensions	640 x 670 x 1135 mm (with optional feeder)
