9
Installation
(continued)
13. Remove the starter toner cartridge from
the silver bag. Vigorously shake the
cartridge to loosen the toner.
•
Thoroughly shaking the cartridge will
assure maximum copies per
cartridge.
•
Xerox has included a Starter Toner
Cartridge. Purchased replacement
toner cartridges will yield
approximately three times the
number of copies.
14. Remove the toner cartridge cover.
15. Slide the toner cartridge into the
WorkCentre until it locks into place.
16. Close the front cover and the side
cover.
Skip to the Printer Driver Software
Installation section in this User Guide to
set up the WorkCentre XD for printing.
17. Plug the power cord into the
WorkCentre and then into a grounded
outlet.
18. Turn on the power switch. In
approximately two seconds the ready
indicator will light. Copying is now
possible.
Note:
Save the carton and packing
materials. They should be used to repack
the WorkCentre if it has to be shipped for
servicing or moved.
