38
– E2 Clearing the Paper Path
(continued)
Exit Area
1
2
Note: Ensure that the alternate paper tray
is lowered (XD104/105f/130df/155df only).
1. Press the release lever to open the side
cover.
2. Press the front cover release buttons to
open the front cover.
3. Pull down on the fuser lever.
•
This will release pressure on the
paper.
4. Turn the knob in the direction of the
arrow to move the paper to the exit
area.
5. Gently pull the paper out through the
exit area.
6. Push up on the fuser lever.
7. Close the front cover and side cover.
To Next Page
