Xilinx AC701 User Manual

AC701 Evaluation Board www.xilinx.com 69
UG952 (v1.3) April 7, 2015
Feature Descriptions
Table 1-32 shows the AC701 TI power system configuration for controller U9.
Table 1-32: Controller U9 Power System Configuration
Sequencer
Schematic
Regulator Type Voltag e Current
Page Page Contents Net Name
#2 U9 PMBus
Addr 102, 5 rails
45 UCD90120A #2
46 Addr 102, Rail 1 VCCO_VADJ LMZ31506 (U56) 2.5V 6A
47 Addr 102, Rail 2 FPGA_1V8 LMZ31503 (U57) 1.8V 3A
48 Addr 102, Rail 3 FPGA_3V3 LMZ31506 (U58) 3.3V 6A
49 Addr 102, Rail 4 MGTAVCC LMZ31503 (U59) 1.0V 3A
50 Addr 102, Rail 5 MGTAVTT LMZ31503 (U60) 1.2V 3A
Send Feedback
