Xilinx KCU105 User Manual

KCU105 Board User Guide www.xilinx.com 11
UG917 (v1.4) September 25, 2015
Chapter 1: KCU105 Evaluation Board Features
19
Dual USB-to-UART Bridge,
Bridge device (U34) with Mini-B Connector (J4)
Silicon Labs CP2105-F01-GM bridge,
Hirose ZX62D-AB-5P8 connector
40
20
HDMI Video Output,
HDMI Controller (U52), HDMI Connector (P6)
Analog Devices ADV7511KSTZ-P,
Molex 47151-001
46, 47
21
I2C Bus, Topology, and Switches,
I2C Bus MUX (U28)
TI TCA9548APWR bottom of board
49
22
I2C Bus, Topology, and Switches,
I2C Bus MUX (U80)
TI PCA9544ARGYR bottom of board
50
23
Status and User LEDs,
User LEDs (DS6-DS10, DS31-DS33)
GPIO LEDs, GREEN 0603
Lumex SML-LX0603GW-TR
41
24
User Pushbuttons,
User Pushbuttons, active-High (SW6-SW10)
E-Switch TL3301EF100QG in North,
South, East, West, Center pattern
41
25
User Pushbuttons,
User CPU RESET, active-High (SW5)
E-Switch TL3301EF100QG
41
26
GPIO DIP Switch,
GPIO DIP Switch (SW12)
4-pole C&K SDA04H1SBD
41
27
Program_B Pushbutton Switch,
FPGA PROG Pushbutton (SW4)
E-Switch TL3301EF100QG
41
28
FPGA Configuration DIP Switch,
DIP Switch (SW15)
6-pole C&K SDA06H1SBD
32
29
User PMOD GPIO Headers,
PMOD Hdrs. (J52,J53) w/Level-Shifters (U41,U42)
2x6 0.1 inch male header Sullins
PBC36DAAN; TI TXS0108EPWR
48
30
Power On/Off Slide Switch SW1,
Power On/Off Switch (SW1)
C&K 1201M2S3AQE2
51
31
KCU105 Board Power System,
Power Management System (top and bottom)
Maxim MAX15301 and MAX15303
Digital P.O.L. Controllers
52 - 65
32
SYSMON Power System Measurement
SYSMON External Circuitry
Analog Devices MUX ADG707BRUZ
TI Op Amps INA333AIDGKR
44 - 45
33
FMC HPC Connector J22,
FMC HPC connector (J22)
Samtec ASP_134486_01
21 - 24
34
FMC LPC Connector J2,
FMC LPC connector (J2)
Samtec ASP_134603_01
25
35
SYSMON Power System Measurement,
SYSMON Header (J75)
2x6 0.1inch male header, part of
breakaway 2x36 Sullins PBC36DAAN
43
36
KCU105 Board Zynq-7000 AP SoC XC7Z010
System Controller,
Zynq-7000 AP SoC XC7Z010CLG225 (U111)
XC7Z010CLG225
29 - 31
Table 1-1: KCU105 Board Component Descriptions (Cont’d)
Callout Component Description Notes
Schematic
(1)
0381556
Page Number
Send Feedback
