Xilinx VCU128 User Manual

Table 23: XCVU37P U1 GTY Transceiver Bank 226 Connections
MGT
Bank
FPGA
(U1)
Pin
FPGA (U1) Pin
Name
Schematic Net
Name TX
1
Connected
Pin
Connected
Pin Name
Connected
Device
GTY bank
226
AU11 MGTYTXP0_226 PCIE_EP_TX7_P A47 PERP7
PCIE 16-lane
edge conn. P1
AU10
MGTYTXN0_226 PCIE_EP_TX7_N A48 PERN7
AU2 MGTYRXP0_226 PCIE_EP_RX7_P B45 PETP7
AU1 MGTYRXN0_226 PCIE_EP_RX7_N B46 PETN7
AT9 MGTYTXP1_226 PCIE_EP_TX6_P A43 PERP6
AT8 MGTYTXN1_226 PCIE_EP_TX6_N A44 PERN6
AT4 MGTYRXP1_226 PCIE_EP_RX6_P B41 PETP6
AT3 MGTYRXN1_226 PCIE_EP_RX6_N B42 PETN6
AR7 MGTYTXP2_226 PCIE_EP_TX5_P A39 PERP5
AR6 MGTYTXN2_226 PCIE_EP_TX5_N A40 PERN5
AR2 MGTYRXP2_226 PCIE_EP_RX5_P B37 PETP5
AR1 MGTYRXN2_226 PCIE_EP_RX5_N B38 PETN5
AR11 MGTYTXP3_226 PCIE_EP_TX4_P A35 PERP4
AR10 MGTYTXN3_226 PCIE_EP_TX4_N A36 PERN4
AP4 MGTYRXP3_226 PCIE_EP_RX4_P B33 PETP4
AP3 MGTYRXN3_226 PCIE_EP_RX4_N B34 PETN4
AN15 MGTREFCLK0P_226
NC NC NC NC
AN14 MGTREFCLK0N_226
AM13 MGTREFCLK1P_226
NC NC NC NC
AM12 MGTREFCLK1N_226
Notes:
1. Series 0.01uF capacitor coupled.
Chapter 3: Board Component Descriptions
UG1302 (v1.0) December 21, 2018 www.xilinx.com
VCU128 Board User Guide 65
Send Feedback
