Appendix A: FPGA Pinouts
R
FPGA #2 Test and Debug Signals
FPGA2_DIP0 AG18 FPGA2_SOFTTOUCH_BY1_B7 H17
FPGA2_DIP1 AG15 FPGA2_SPYHOLE_BK15 P29
FPGA2_DIP2 AH15 FPGA2_SPYHOLE_BK18 W9
FPGA2_DIP3 AG20 FPGA2_TEST_HDR_BY0_B0 AE23
FPGA2_SOFTTOUCH_BY0_B0 H20 FPGA2_TEST_HDR_BY0_B1 AE22
FPGA2_SOFTTOUCH_BY0_B1 H19 FPGA2_TEST_HDR_BY0_B2 AG12
FPGA2_SOFTTOUCH_BY0_B2 H13 FPGA2_TEST_HDR_BY0_B3 AF13
FPGA2_SOFTTOUCH_BY0_B3 J14 FPGA2_TEST_HDR_BY0_B4 AG23
FPGA2_SOFTTOUCH_BY0_B4 J21 FPGA2_TEST_HDR_BY0_B5 AF23
FPGA2_SOFTTOUCH_BY0_B5 J20 FPGA2_TEST_HDR_BY0_B6 AE12
FPGA2_SOFTTOUCH_BY0_B6 H15 FPGA2_TEST_HDR_BY0_B7 AE13
FPGA2_SOFTTOUCH_BY0_B7 H14 FPGA2_TEST_HDR_BY1_B0 K12
FPGA2_SOFTTOUCH_BY1_B0 J19 FPGA2_TEST_HDR_BY1_B1 K13
FPGA2_SOFTTOUCH_BY1_B1 K18 FPGA2_TEST_HDR_BY1_B2 H23
FPGA2_SOFTTOUCH_BY1_B2 G16 FPGA2_TEST_HDR_BY1_B3 G23
FPGA2_SOFTTOUCH_BY1_B3 G15 FPGA2_TEST_HDR_BY1_B4 H12
FPGA2_SOFTTOUCH_BY1_B4 L18 FPGA2_TEST_HDR_BY1_B5 J12
FPGA2_SOFTTOUCH_BY1_B5 K17 FPGA2_TEST_HDR_BY1_B6 K22
FPGA2_SOFTTOUCH_BY1_B6 H18 FPGA2_TEST_HDR_BY1_B7 K23
FPGA #2 Test Display Signals
FPGA2_7SEG_0_N AG17 FPGA2_7SEG_6_N AF19
FPGA2_7SEG_1_N AH18 FPGA2_7SEG_DP_N AG21
FPGA2_7SEG_2_N AE18 FPGA2_LED0 AD19
FPGA2_7SEG_3_N AF18 FPGA2_LED1 AE19
FPGA2_7SEG_4_N AG16 FPGA2_LED2 AE17
FPGA2_7SEG_5_N AH17 FPGA2_LED3 AF16
FPGA #2 External Interfaces
FPGA2_116_TX0_N G2 FPGA2_120_RX1_P D1
FPGA2_116_TX0_P F2 FPGA2_124_TX0_N B10
FPGA2_120_RX0_N A2 FPGA2_124_TX0_P B9
FPGA2_120_RX0_P A3 FPGA2_124_TX1_N B6
FPGA2_120_RX1_N C1 FPGA2_124_TX1_P B5
Table A-2: FPGA #2 Pinout (Continued)
Signal Name Pin Signal Name Pin
