Xilinx Virtex-5 FPGA ML561

46 www.xilinx.com Virtex-5 FPGA ML561 User Guide
UG199 (v1.2.1) June 15, 2009
Chapter 4: Electrical Requirements
R
FPGA Internal Power Budget
Table 4-4 summarizes power consumption estimates by each of the three
XC5VLX50T-FFG1136 FPGAs on the Virtex-5 FPGA ML561 Development Board. This
estimate derives the FPGA utilization information from the respective map report of a fully
configured reference design.
Table 4-4: ML561 FPGA Power Estimate Summary
FPGA # FPGA #1 FPGA #2
(1)
FPGA #3
Interface
DDR400 Comp
(DCI)
DDR2 Comp
(DCI)
DDR2 DIMM
(DCI)
QDRII (DCI)
RLDRAM II
(DCI)
I/O Standard SSTL_18 HSTL_18 HSTL_18
Total Power (W) 3.7 3.1 10.2 6.3 4.5
V
CCINT
(1.0V) mW 763 763 1945 1160 1515
V
CCAUX
(2.5V) mW 435 544 544 544 544
SSTL_18 V
CCO
(1.8V) mW 1819 7664
SSTL_2 V
CCO
(2.6V) mW 2469
HSTL_18 V
CCO
(1.8V) mW 4571 2406
I/O Frequency (MHz) 200 400 400 400 400
Fabric Frequency (MHz) 200 200 200 200 200
Number of Slices 1500 1500 5910 2750 1951
Number of Flip-flops 2000 2000 7352 2000 1800
Number of Shift Register LUTs 50 50 143 750 400
Number of Block RAMs 5 5 17 14 21
Number of DCMs 2 2 2 2 2
Inputs 10 10 10 90 13
Outputs 50 50 90 160 52
Bidirectionals 36 40 192 0 36
Ambient Temperature (°C) 25 25 25 25 25
Airflow (LFM) 0 0 250 250 0
Heat Sink (Theta-J) n/a n/a 5 5 n/a
Junction Temperature (°C) 67 60 78 58 76
Notes:
1. For DDR2 DIMMs as well as QDRII memory interfaces with DCI, an MD35E-10B heat sink is needed. A heat sink with Theta-J = 5.0
should be okay without airflow. See http://www.alphanovatech.com/c_md35e.html
for the heat sink profile. A heat sink with
Theta-J = 5.0 might need airflow of 250 LFM.
