ZC706 Evaluation Board User Guide www.xilinx.com 41
UG954 (v1.5) September 10, 2015
Feature Descriptions
Table 1-14 lists the GTX Banks 109 and 110 interface connections between the AP SoC U1
and FMC HPC connector J37.
Table 1-14: AP SoC GTX Banks 109 and 110 Interface Connections to FMC HPC J37
Transceiver
Bank
AP SoC U1
Pin
Number
AP SoC U1 Pin Name Schematic Net Name
Connected
Pin
Connected
Device
GTX_BANK_109
AK10 MGTPTXP0_109 FMC_HPC_DP0_C2M_P C2
FMC HPC
J37
AK9 MGTPTXN0_109 FMC_HPC_DP0_C2M_N C3
AH10 MGTPRXP0_109 FMC_HPC_DP0_M2C_P C6
AH9 MGTPRXN0_109 FMC_HPC_DP0_M2C_N C7
AK6 MGTPTXP1_109 FMC_HPC_DP1_C2M_P A22
AK5 MGTPTXN1_109 FMC_HPC_DP1_C2M_N A23
AJ8 MGTPRXP1_109 FMC_HPC_DP1_M2C_P A2
AJ7 MGTPRXN1_109 FMC_HPC_DP1_M2C_N A3
AJ4 MGTPTXP2_109 FMC_HPC_DP2_C2M_P A26
AJ3 MGTPTXN2_109 FMC_HPC_DP2_C2M_N A27
AG8 MGTPRXP2_109 FMC_HPC_DP2_M2C_P A6
AG7 MGTPRXN2_109 FMC_HPC_DP2_M2C_N A7
AK2 MGTPTXP3_109 FMC_HPC_DP3_C2M_P A30
AK1 MGTPTXN3_109 FMC_HPC_DP3_C2M_N A31
AE8 MGTPRXP3_109 FMC_HPC_DP3_M2C_P A10
AE7 MGTPRXN3_109 FMC_HPC_DP3_M2C_N A11
AD10 MGTREFCLK0P_109 FMC_HPC_GBTCLK0_M2C_C_P
(1)
D4
AD9 MGTREFCLK0N_109 FMC_HPC_GBTCLK0_M2C_C_N
(1)
D5
AF10 MGTREFCLK1P_109 NC NA NA
AF9 MGTREFCLK1N_109 NC NA NA
