Feature Descriptions
Table 1-23 lists the connections between the codec and the XC7Z045 AP SoC.
Table 1-23: XC7Z045 AP SoC U1 to HDMI Codec Connections (ADV7511)
XC7Z045 (U1)
Pin
Net Name I/O Standard
ADV7511 (U53)
Pin Number Pin Name
U24 HDMI_R_D4 LVCMOS25 92 D4
T22 HDMI_R_D5 LVCMOS25 91 D5
R23 HDMI_R_D6 LVCMOS25 90 D6
AA25 HDMI_R_D7 LVCMOS25 89 D7
AE28 HDMI_R_D8 LVCMOS25 88 D8
T23 HDMI_R_D9 LVCMOS25 87 D9
AB25 HDMI_R_D10 LVCMOS25 86 D10
T27 HDMI_R_D11 LVCMOS25 85 D11
AD26 HDMI_R_D16 LVCMOS25 80 D16
AB26 HDMI_R_D17 LVCMOS25 78 D17
AA28 HDMI_R_D18 LVCMOS25 74 D18
AC26 HDMI_R_D19 LVCMOS25 73 D19
AE30 HDMI_R_D20 LVCMOS25 72 D20
Y25 HDMI_R_D21 LVCMOS25 71 D21
AA29 HDMI_R_D22 LVCMOS25 70 D22
AD30 HDMI_R_D23 LVCMOS25 69 D23
Y28 HDMI_R_D28 LVCMOS25 64 D28
AF28 HDMI_R_D29 LVCMOS25 63 D29
V22 HDMI_R_D30 LVCMOS25 62 D30
AA27 HDMI_R_D31 LVCMOS25 61 D31
U22 HDMI_R_D32 LVCMOS25 60 D32
N28 HDMI_R_D33 LVCMOS25 59 D33
V21 HDMI_R_D34 LVCMOS25 58 D34
AC22 HDMI_R_D35 LVCMOS25 57 D35
V24 HDMI_R_DE LVCMOS25 97 DE
R22 HDMI_R_HSYNC LVCMOS25 98 HSYNC
U21 HDMI_R_VSYNC LVCMOS25 2 VSYNC
P28 HDMI_R_CLK LVCMOS25 79 CLK
AC23 HDMI_INT LVCMOS25 45 INT
AC21 HDMI_R_SPDIF LVCMOS25 10 SPDIF
AB22 HDMI_SPDIF_OUT_LS LVCMOS25 46 SPDIF_OUT
