Xilinx ZCU102 User Manual

ZCU102 Evaluation Board User Guide www.xilinx.com 111
UG1182 (v1.2) March 20, 2017
Chapter 3: Board Component Descriptions
The ZCU102 evaluation board uses power regulators and PMBus compliant POL controllers
from Maxim Integrated Circuits [Ref 21] to supply the core and auxiliary voltages listed in
Table 3-55. The schematic page references are to 0381701.
Table 3-55: ZCU102 Power System Devices
Device Type
Ref.
Des.
PMBus
Address
Description
Power Rail Net
Name
Power Rail
Voltage
INA226
Address
Schematic
Page
MAX15301 U47
0x13
Maxim InTune digital POL
controller 40A
VCCINT 0.85V
0x40
60
MAX15303 U7
0x14
Maxim InTune digital POL
controller 6A
VCCBRAM 0.85V
0x41
61
MAX15303 U6
0x15
Maxim InTune digital POL
controller 3A
VCCAUX 1.80V
0x42
62
MAX15303 U10
0x16
Maxim InTune digital POL
controller 2A
VCC1V2 1.20V
0x43
63
MAX15303 U9
0x17
Maxim InTune digital POL
controller 5A
VCC3V3 3.30V
0x44
64
MAX15301 U63
0x18
Maxim InTune digital POL
controller 10A
VADJ_FMC 1.80V
0x45
65
MAX15027 U38
N/A
Maxim LDO Regulator 1A PL_DDR4_VPP_2V5 2.5V
N/A
66
MAX20751EKX U95
0x72
Maxim multiphase master
with smart slave VT77518 6A
MGTAVCC 0.90V
0x46
67
MAX20751EKX U96
0x73
Maxim multiphase master
with smart slave VT77518 6A
MGTAVTT 1.20V
0x47
68
MAX8869E U14
N/A
Maxim LDO Regulator 1A MGTVCCAUX 1.81V
NA
69
MAX15301 U46
0x0A
Maxim InTune digital POL
controller 10A
VCCPSINTFP 0.85V
0x40
70
MAX15303 U4
0x0B
Maxim InTune digital POL
controller 2A
VCCPSINTLP 0.85V
0x41
71
MAX8869E U3
N/A
Maxim LDO Regulator
500 MA
VCCPSAUX 1.81V
0x42
72
MAX8869E U17
N/A
Maxim LDO Regulator
200 MA
VCCPSPLL 1.20V
0x43
73
MAX8869E U5
N/A
Maxim LDO Regulator
400 MA
MGTRAVCC 0.85V
0x44
74
MAX8869E U12
N/A
Maxim LDO Regulator
100 MA
MGTRAVTT 1.81V
0x45
75
MAX15303 U18
0x1D
Maxim InTune digital POL
controller 6A
DDR4_DIMM_VDD
Q
1.20V
N/A
76
MAX15027 U39
N/A
Maxim LDO Regulator 1A PS_DDR4_VPP_2V5 2.50V
N/A
77
MAX15303 U13
0x10
Maxim InTune digital POL
controller 4A
VCCOPS 1.80V
0x47
78
MAX8869E U31
N/A
Maxim LDO Regulator
300 MA
VCCOPS3 1.81V
0x4A
79
MAX8869E U30
N/A
Maxim LDO Regulator
100 MA
VCCPSDDRPLL 1.81V
0x4B
80
Send Feedback

Xilinx ZCU102 Specifications

General

Processor	Quad-core ARM Cortex-A53, Dual-core ARM Cortex-R5
SD Card	MicroSD card slot
Video Outputs	DisplayPort
FPGA	Xilinx Zynq UltraScale+ XCZU9EG-2FFVB1156E
Memory	4GB DDR4 Component Memory
Storage	MicroSD card slot
Ethernet	Gigabit Ethernet
USB	1 x USB 3.0, 1 x USB 2.0
PCIe	PCIe Gen2 x4
Display	DisplayPort
Power Supply	12V DC input
SATA	SATA 3.0
Clocking	Programmable clocks
Operating System Support	PetaLinux
