Xilinx ZCU102 User Manual

ZCU102 Evaluation Board User Guide www.xilinx.com 18
UG1182 (v1.2) March 20, 2017
Chapter 2: Board Setup and Configuration
J7
USB ULPI Device or Host select
• 1-2: HOST/OTG
•Open: Device
OPEN 20 51
J113
USB ULPI Device/Host or OTG select
• 1-2: Device or Host
•2-3: OTG
1-2 21 51
J88
ARM Trace VTREF
• 1-2: 3.3V
•Open: 0V
1-2 22 54
J38
ARM Trace power
• 1-2: 3.3V
•Open: 0V
1-2 23 54
J153
Power inhibit
• OFF: rails power on normally
• 1-2: all rails (except UTIL) OFF
OFF 24 59
J9
PS_DDR4_VPP_2V5 power inhibit (U39)
• OFF: rail powers on normally
• 1-2: PS_DDR4_VPP_2V5 OFF
OFF 25 77
J164 MSP430 firmware upgrade header OFF 26 38
Table 2-3: Default Jumper Settings (Cont’d)
Jumper Function Default
Figure 2-2
Callout
Schematic
Page
Send Feedback

Xilinx ZCU102 Specifications

General

Processor	Quad-core ARM Cortex-A53, Dual-core ARM Cortex-R5
SD Card	MicroSD card slot
Video Outputs	DisplayPort
FPGA	Xilinx Zynq UltraScale+ XCZU9EG-2FFVB1156E
Memory	4GB DDR4 Component Memory
Storage	MicroSD card slot
Ethernet	Gigabit Ethernet
USB	1 x USB 3.0, 1 x USB 2.0
PCIe	PCIe Gen2 x4
Display	DisplayPort
Power Supply	12V DC input
SATA	SATA 3.0
Clocking	Programmable clocks
Operating System Support	PetaLinux
