ZCU102 Evaluation Board User Guide www.xilinx.com 27
UG1182 (v1.2) March 20, 2017
Chapter 3: Board Component Descriptions
AD27
DDR4_SODIMM_DQ45 190 DQ45
AD29
DDR4_SODIMM_DQ46 203 DQ46
AD30
DDR4_SODIMM_DQ47 204 DQ47
AH33
DDR4_SODIMM_DQ48 216 DQ48
AJ34
DDR4_SODIMM_DQ49 215 DQ49
AH34
DDR4_SODIMM_DQ50 228 DQ50
AH32
DDR4_SODIMM_DQ51 229 DQ51
AK34
DDR4_SODIMM_DQ52 211 DQ52
AK33
DDR4_SODIMM_DQ53 212 DQ53
AL32
DDR4_SODIMM_DQ54 224 DQ54
AL31
DDR4_SODIMM_DQ55 225 DQ55
AG33
DDR4_SODIMM_DQ56 237 DQ56
AG34
DDR4_SODIMM_DQ57 236 DQ57
AF32
DDR4_SODIMM_DQ58 249 DQ58
AF33
DDR4_SODIMM_DQ59 250 DQ59
AD31
DDR4_SODIMM_DQ60 232 DQ60
AD32
DDR4_SODIMM_DQ61 233 DQ61
AD34
DDR4_SODIMM_DQ62 245 DQ62
AD33
DDR4_SODIMM_DQ63 246 DQ63
AN31
DDR4_SODIMM_CB0 92 CB0/NC
AP31
DDR4_SODIMM_CB1 91 CB1/NC
AP32
DDR4_SODIMM_CB2 101 CB2/NC
AP33
DDR4_SODIMM_CB3 105 CB3/NC
AM31
DDR4_SODIMM_CB4 88 CB4/NC
AM33
DDR4_SODIMM_CB5 87 CB5/NC
AM34
DDR4_SODIMM_CB6 100 CB6/NC
AL33
DDR4_SODIMM_CB7 104 CB7/NC
AN17
DDR4_SODIMM_DM0_B 12 DM0_N/DBI0_N
AM21
DDR4_SODIMM_DM1_B 33 DM1_N/DBI1_N
AK19
DDR4_SODIMM_DM2_B 54 DM2_N/DBI2_N
AH24
DDR4_SODIMM_DM3_B 75 DM3_N/DBI3_N
AH31
DDR4_SODIMM_DM4_B 178 DM4_N/DBI4_N
AE30
DDR4_SODIMM_DM5_B 199 DM5_N/DBI5_N
AJ31
DDR4_SODIMM_DM6_B 220 DM6_N/DBI6_N
Table 3-3: DDR4 SODIMM Socket J1 Connections to FPGA PS DDR Bank 504 (Cont’d)
XCZU9EG
(U1) Pin
Net Name
DDR4 SODIMM Memory J1
Pin Number Pin Name
Send Feedback

Xilinx ZCU102 Specifications

General

Processor	Quad-core ARM Cortex-A53, Dual-core ARM Cortex-R5
SD Card	MicroSD card slot
Video Outputs	DisplayPort
FPGA	Xilinx Zynq UltraScale+ XCZU9EG-2FFVB1156E
Memory	4GB DDR4 Component Memory
Storage	MicroSD card slot
Ethernet	Gigabit Ethernet
USB	1 x USB 3.0, 1 x USB 2.0
PCIe	PCIe Gen2 x4
Display	DisplayPort
Power Supply	12V DC input
SATA	SATA 3.0
Clocking	Programmable clocks
Operating System Support	PetaLinux
