Xilinx ZCU102 User Manual

ZCU102 Evaluation Board User Guide www.xilinx.com 28
UG1182 (v1.2) March 20, 2017
Chapter 3: Board Component Descriptions
AE34
DDR4_SODIMM_DM7_B 241 DM7_N/DBI7_N
AN34
DDR4_SODIMM_DM8_B 96 DM8_N/DBI8_N/NC
AN18
DDR4_SODIMM_DQS0_T 13 DQS0_T
AN19
DDR4_SODIMM_DQS0_C 11 DQS0_C
AN21
DDR4_SODIMM_DQS1_T 34 DQS1_T
AN22
DDR4_SODIMM_DQS1_C 32 DQS1_C
AH19
DDR4_SODIMM_DQS2_T 55 DQS2_T
AJ19
DDR4_SODIMM_DQS2_C 53 DQS2_C
AH22
DDR4_SODIMM_DQS3_T 76 DQS3_T
AH23
DDR4_SODIMM_DQS3_C 74 DQS3_C
AH28
DDR4_SODIMM_DQS4_T 179 DQS4_T
AH29
DDR4_SODIMM_DQS4_C 177 DQS4_C
AE28
DDR4_SODIMM_DQS5_T 200 DQS5_T
AE29
DDR4_SODIMM_DQS5_C 198 DQS5_C
AJ32
DDR4_SODIMM_DQS6_T 221 DQS6_T
AK32
DDR4_SODIMM_DQS6_C 219 DQS6_C
AE32
DDR4_SODIMM_DQS7_T 242 DQS7_T
AE33
DDR4_SODIMM_DQS7_C 240 DQS7_C
AN32
DDR4_SODIMM_DQS8_T 97 DQS8_T
AN33
DDR4_SODIMM_DQS8_C 95 DQS8_C
AN27
DDR4_SODIMM_CK0_C 139 CK0_C
AN26
DDR4_SODIMM_CK0_T 137 CK0_T
AL27
DDR4_SODIMM_CK1_C 140 CK1_C/NF
AL26
DDR4_SODIMM_CK1_T 138 CK1_T/NF
AN29
DDR4_SODIMM_CKE0 109 CKE0
AJ27
DDR4_SODIMM_CKE1 110 CKE1
AM30
DDR4_SODIMM_ODT0 155 ODT0
AJ26
DDR4_SODIMM_ODT1 161 ODT1
AM24
DDR4_SODIMM_RAS_B 152 RAS_N/A16
AK24
DDR4_SODIMM_CAS_B 156 CAS_N/A15
AK25
DDR4_SODIMM_WE_B 151 WE_N/A14
AG25
DDR4_SODIMM_ACT_B 114 ACT_N
AF22
DDR4_SODIMM_ALERT_B 116 ALERT_N
AF20
DDR4_SODIMM_PARITY 143 PARITY
Table 3-3: DDR4 SODIMM Socket J1 Connections to FPGA PS DDR Bank 504 (Cont’d)
XCZU9EG
(U1) Pin
Net Name
DDR4 SODIMM Memory J1
Pin Number Pin Name
Send Feedback

Xilinx ZCU102 Specifications

General

Processor	Quad-core ARM Cortex-A53, Dual-core ARM Cortex-R5
SD Card	MicroSD card slot
Video Outputs	DisplayPort
FPGA	Xilinx Zynq UltraScale+ XCZU9EG-2FFVB1156E
Memory	4GB DDR4 Component Memory
Storage	MicroSD card slot
Ethernet	Gigabit Ethernet
USB	1 x USB 3.0, 1 x USB 2.0
PCIe	PCIe Gen2 x4
Display	DisplayPort
Power Supply	12V DC input
SATA	SATA 3.0
Clocking	Programmable clocks
Operating System Support	PetaLinux
